Six Type-45 positions
The floor outlet accepts a project-specific combination of Type-45 power, USB, data and multimedia modules.
Green Home floor boxes
Stainless steel · 6 modules
GH-SOP-146S 6-module stainless steel floor box
A low-profile stainless steel floor outlet box with six Type-45 module positions and protected cable-exit flaps for concrete floors.
Request datasheet
Project applications
Designed for practical floor access.
- Offices
- Meeting rooms
- Retail areas
- Internal concrete floors
Technical specification
- Module capacity
- 6 Type-45 modules
- Panel / cut-out
- 146 × 146 mm / 138 × 138 mm
- Product body
- 135 × 135 mm reference
- Depth
- 80 mm overall; 75 mm box depth
- Cover
- Stainless steel cover and frame
- Cable management
- Hinged cover with two protected cable-exit flaps
- Certification
- CE and TÜV
- Application
- Concrete-floor applications
Configuration and finishes
The details that affect selection.
Protected cable exit
Two protected cable-exit flaps support outgoing cables and help reduce bending and pinching while the cover is in use.
Flexible orientation
The internal panel can be rotated by 90 degrees during installation to suit the cable direction.
Low-profile concrete-floor fit
The supplied datasheet lists a 146 × 146 mm panel, a 138 × 138 mm cut-out and 80 mm overall depth for recessed concrete-floor installation.
Questions and answers
Product details, clearly answered.
How many modules can be fitted?
The box accepts six Type-45 power, USB, data and multimedia modules selected for the project.
Which concrete-floor cut-out is required?
The supplied datasheet lists a 138 by 138 mm cut-out.
Can cables exit while the cover is in use?
Yes. The hinged cover includes two protected cable-exit flaps for cable routing.
