MK Onix IP44 Pop-up Grommets
A premium pop-up/grommet direction from the MK Onix Plus floor series for power and data access in finished floors.
Product overview
MK Onix IP44 Pop-up Grommets
MK Onix IP44 Grommets are part of the Onix Plus floor series by MK Electric, a Honeywell brand. They provide a clean pop-up floor access point for power and data in screed, underfloor, desk, and raised-floor applications. The system is designed around a minimal visual footprint, wet-wash sealing, multiple module sizes, and three premium finishes for projects where the floor detail is visible to users.
Best for
Reception areas, showrooms, airports, offices, shopping malls, exhibition halls, hospitality spaces, marble floors, stone floors, and carpeted commercial interiors.
Colours and finishes
Stainless SteelMatt BlackBrass
Technical specification
Product type
Pop-up floor grommet for power and data modules
Protection
IP44 wet-wash rating for suitable commercial applications
Applications
Screed floors, raised floors, underfloor systems, desk and floor power distribution
Module sizes
3, 4, 6, and 8 module grommet options
Load rating
Tested to EN 50085-2-2 to accept 5 kN
Impact rating
IK10 impact resistance stated in brochure
Base depth
Common 60 mm base direction, with 65 mm noted for 4 module base unit
Compatibility
Compatible with standard Euro modules; supplied base/back box options vary by configuration
IP44 wet-wash protectionPop-up opening3, 4, 6, and 8 module options5 kN load rating
Questions and answers
MK Onix IP44 Pop-up Grommets questions, clearly answered.
What protection rating does MK Onix provide?
MK Onix Pop-up Grommets are specified with an IP44 wet-wash rating for suitable commercial applications. Verify the final installed configuration and project condition before specification.
Which module sizes are available for MK Onix Pop-up Grommets?
MK Onix is available in 3, 4, 6 and 8 module grommet options.
What load rating is stated for MK Onix?
The MK Onix range is tested to EN 50085-2-2 to accept a 5 kN load.
